Model
|
PL925
|
|
SoC
|
|
CPU
|
4 ARM®1.5GHz Cortex-A55
|
|
APU
|
MDLA 4TOPs, 1X MVPU
|
|
Flash
|
NAND FLASH 4Gb
|
|
DDR
|
LPDDR4X 8Gb *2
|
|
Camera
|
|
Image Sensor
|
1/1.8" RGB CMOS
|
|
Max. Resolution
|
3840x2160
|
|
Lens
|
Vari-focal 4~10mm, F1.35, P-iris, HFOV: 110~46.2°
|
|
Day/Night
|
Automatically removable infrared-cut filter
|
|
Sensor HDR
|
78dB
|
|
Min. illumination
|
Color: 0.1lux@F1.35, B/W: 0.01lux@F1.35
|
|
Shutter Speed
|
1/10s~1/32000s
|
|
Video
|
|
Video Compression
|
H.265, H.264
|
|
Resolutions
|
3840x2160, 2560x1440, 1920x1080, 1280x720, 800x450, 640x360, 320x180
|
|
Max. Frame Rate
|
up to 20/30 fps (50/60 Hz)
|
|
Multiple Streams
|
3 video streams
|
|
Video Streaming
|
Individually configurable video format, resolution, quality and bit rate control
|
|
Image Settings
|
Exposure: exposure control (iris adjustment, exposure time, gain control, iris mode), AE speed adjustment, HDR
|
|
Image settings: white balance(AI-AWB), image adjustment (brightness, contrast, saturation, sharpness), 3DNR, dehaze
|
|
Video settings: video title and time stamp overlay, video orientation (flip, mirror), day/night settings, Privacy mask
|
|
Alarm and Event
|
|
Event Trigger
|
Periodical/Schedule trigger, AI object/event detection
|
|
Event Actions
|
Video file upload via onboard storage, email and FTP
|
|
Network
|
|
Interface
|
10BASE-T/100BASE-TX/1000BASE-T
|
|
Protocol
|
DHCP, DNS, FTP, HTTP, IPv4, NTP, RTSP/RTP/RTCP, SMTP, TCP/IP
|
|
General
|
|
Housing
|
IP67, IK10
|
|
Power
|
DC 12V, IEEE 802.3af/at PoE
|
|
Local Storage
|
Support M2 SATA (Option) and MicroSD/SDHC/SDXC card slot
|
|
Operating Temperature
|
-20 to 60
|
