| System Information |
Interface |
10 Base-T/100 BaseTX Ethernet(RJ-45) |
|
| CPU |
Multimedia SoC (System-on-Chip) |
ONVIF |
Ver. 2.2 |
|
| NOR Flash |
16MB |
Intelligent Video |
|
| RAM |
512 MB |
Motion Detection |
Ten-window video motion detection |
|
| Camera Features |
Alarm and Event |
|
| Max. Resolution |
1440x1440 |
Alarm Triggers |
Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification |
|
| Lens Type |
Fisheye Fix Lens |
|
| Focal Length |
f=1.05 mm |
Alarm Events |
Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS
server |
|
| Aperture |
F= 2.8 |
|
| Field of View |
180° (Horizontal/Vertical/Diagonal) |
General |
|
| WDR Technology |
WDR Enhanced |
Connectors |
RJ-45 cable connector for Network/PoE
Audio input*1, Audio output*1
DC 12V power input
Digital input*1, Digital output*2 |
|
| Day/Night |
Removable IR-cut filter for day & night function |
|
| Min. Illumination |
1.9 Lux @F2.8 (Color) ; 0.1 Lux @F2.8 (B/W) |
|
| Pan/Tilt/Zoom |
ePTZ: 10x digital zoom |
Power Input |
DC 12V
IEEE 802.3af PoE
|
|
| On-board Storage |
Built-in MicroSD card slot,
support SDHC/SDXC 64GB or above
|
|
| Video |
Power Consumption |
Max. 5.1 W (DC 12V)
Max. 5.3 W (PoE) |
|
| Compression |
H.264, MJPEG & MPEG-4 |
|
| Display Mode |
360° Source View, 360° Broad View, 180° Double Broad View, Triple View, Quad View, 3 PTZ with Source View |
Wireless |
IEEE802.11b/g/n (Optional) |
|
| Dimension |
Ø:196 x 57.3mm |
|
| Weight |
Net: 350g |
|
Maximum
Frame Rate |
15 fps at 1440x1440
15 fps at 1600x1200
15 fps at 1280x1024
15 fps at 800x600, 640x480 |
Safety Certifications |
CE, FCC Class B, LVD |
|
| Operating Temperature |
0°C ~ 50°C |
|
| Operating Humidity |
10% ~ 80% |
|
| Max Streams |
3 simultaneous streams |
System Requirements |
|
| Operating System |
Microsoft Windows 7/Vista/XP/2000 |
|
| S/N Ratio |
Above 39 dB |
Web Browser |
Mozilla Firefox 7 ~ 10, Internet Explorer 7.x or 8.x, Chrome / Safari 4.0 or above |
|
| Dynamic Range |
100 dB |
|
| Video Streaming |
Adjustable resolution, quality and bitrate
ROI Provide Outstanding e-PTZ Function |
Other Players |
VLC: 1.1.11 or above |
|
| Image Settings |
Adjustable image size, quality and bitrate Configurable brightness, saturation, exposure control, sharpness, contrast, white balance, auto shutter control, auto gain control, noise reduction, EV luminance control, flip & mirror, privacy masks, time stamp, text overlay |
Included Accessories |
|
Quick installation guide, screws pack, mounting bracket,
software CD |
|
| Dimensions |
|
  |
|
| Audio |
|
| Audio Capability |
Audio input/output (full duplex) |
|
| Compression |
G.711u |
|
| Interface |
Built-in microphone, External microphone input |
|
| Effective Range |
5 meters |
|
| Network |
|
| Users |
Live viewing for up to 10 clients |
|
| Protocols |
HTTP,HTTPS, TCP/ IP,IPv4, UDP, SMTP, FTP, DHCP, DDNS, NTP, DNS, ARP,RTSP, RTP, UPnP, ONVIF(Profile S), Multicast |
|
